Lưu lượng kế dạng phao Trogflux Mecon
| Measuring ranges | Liquids¹: 6.5 … 25,000 l/h Gases²: 140 … 480,000 l/h |
| Measuring accuracy due to VDI / VDE 3513-2 (qG = 50 %) |
Liquids: 2,5 Gases: 2,5 |
| Pressure limits | Trogamid: max. 10 bar Polysulfone: max. 10 bar ( |
| Temperature limits | Trogamid: -10 °C … +60 °C Polysulfone: -10 °C … +90 °C |
| Flow direction | vertically upwards |
| Process connections | DIN ISO 228: G ¼ … G 2 ANSI B1.20.1: ¼“ … 2“ Adhesive bushing: 20 … 63 mm |
| Float materials | Stainless steel, PVC, PVDF, aluminum |
| Options | Contact(s) |
¹ Standard measurement range for liquids (ρ = 1 kg/l, viscosity 1 mPa.s)
² Standard measurement range for gases (Pe = 0 bar pressure, T = 0 °C, ρ = 1,293 kg/m³, v = 0,0181 mPa.s)
